be correct by the bus master, a programming pulse can be issued to program the byte position within the EPROM
status field pointed to by T15:T0. Following the programming pulse, the bus master must issue 8 read timeslots.
The read timeslots return the EPROM status byte value (least significant bit first) for confirmation by the master.
The bus master can issue a reset pulse at any point after issuing the program pulse to end the write operation, or
continue the write operation with the next byte in the EPROM status field. If the write operation is continued, the
DS25LV02 automatically increments the internal address pointer to select the next byte in the EPROM status field,
and the new value of T7:T0 is loaded into the 8-bit CRC generator as the starting value. The bus master issues the
next 1-byte data argument followed by 8 read timeslots to return the CRC computed by the DS25LV02. The value
returned is computed with D7:D0, using T7:T0 as the starting value. If the CRC is deemed to be incorrect by the
bus master, the bus master should issue a reset pulse and repeat the entire sequence. If the CRC is deemed to be
correct by the bus master, a programming pulse can be issued to program the byte position pointed to by T15:T0.
Following the programming pulse, the bus master must issue 8 read timeslots. The read timeslots return the
EPROM status byte value (least significant bit first) for confirmation by the master.
The write operation can be continued until the end of the EPROM status field is reached by repeating the sequence
of issuing a 1-byte data argument, 8 read timeslots to return CRC, a programming pulse, and 8 read timeslots to
return EPROM byte value.
Table 2. EPROM Status Field
ADDRESS (HEX)
0000
0001
0002
0003
0004
0005-0006
0007
DESCRIPTION
Write Protect Page bits
B0: Page 0 Write Protect
B1: Page 1 Write Protect
B2: Page 2 Write Protect
B3: Page 3 Write Protect
B4: Reserved for TMEX
B5: Reserved for TMEX
B6: Reserved for TMEX
B7: Reserved for TMEX
Page Redirection Byte for Page 0
Page Redirection Byte for Page 1
Page Redirection Byte for Page 2
Page Redirection Byte for Page 3
Reserved
Factory Programmed to 00h
READ/WRITE
R/W*
R/W*
R/W*
R/W*
R/W*
R
R
* One-time write to “0” for each bit.
